Specification
|
|
Eyepiece
|
Wide field WF10X(field number:¦µ22mm)
|
|
Objective
|
Equipped with bright field objectives
|
PL L10X/0.25 (Work distance)：20.2 mm
|
|
PL L20X/0.40 (Work distance)：8.80 mm
|
|
PL L50X/0.70 (Work distance)：3.68 mm
|
|
PL L100X/0.85£¨Dry£© (Work distance)：0.40 mm
|
|
Equipped with bright & dark field objectives
|
PL L5X/0.12 BD (Work distance)：9.70 mm
|
|
PL L10X/0.25 BD (Work distance)：9.30 mm
|
|
PL L20X/0.40 BD (Work distance)：7.23mm
|
|
PL L50X/0.70 BD (Work distance)：2.50 mm
|
|
Eyepiece tube
|
Inclination angle is 45˚ and interpupillary distance is 53~75mm.
|
|
Focus system
|
Coaxial coarse/fine focus, with tension adjustable£¬minimum division of fine focusing is 2μm.
|
|
Nosepiece
|
Quintuple (Backward ball bearing inner locating)
|
|
Stage
|
Mechanical stage overall size: 242mmX200mm and moving range : 30mmX30mm.
|
|
Rotundity and rotatable stage size: maximal measurement is Ф130mm and minimal clear aperture is less then Ф12mm.
|
|
Illumination system
|
6V30W halogen and brightness enable control.,
|
|
12V50W halogen and brightness enable control.,
|
|
Integrated field diaphragm , aperture diaphragm and puller type polarizer.
|
|
Equipped with frosted glass and yellow , green and blue filters
|
